12V / 24V Slim LED Power Supply Range
A slim and compact LED power-supply range with 12V or 24V outputs, model-specific wattage ratings and enclosure dimensions.
- Model
- ULT-9CD28B56
- Product type
- LED power supplies and adapters
- Available configurations
- 33
PRODUCT OVERVIEW
12V / 24V Slim LED Power Supply Range
This power-supply range covers 12V and 24V output models in slim and compact metal-case formats. Each SKU identifies its output voltage, rated power and dimensions; selected export versions use encapsulated cases. A separate 3 m, 0.75 mm² power cable is also listed. The existing SKU data does not state the input voltage, so it must be confirmed for the exact unit before ordering or installation. Compatible 2835, 5050 and 5630 LED loads are applications, not technologies inside the power supply.
- 12V and 24V output choices
- 18W to 400W listed power ratings
- Model-specific slim and compact dimensions
- Selected encapsulated export versions
PARAMETERS
Review the available product details.
- Input voltage
- not stated in the existing SKU data
- Output / rated power
- 12V 18–400W or 24V 24–400W, depending on SKU
- Dimensions
- 90 × 35 × 23 mm to 375 × 18 × 18 mm across listed power-supply models
- Separate accessory
- 3 m, 0.75 mm² power cable
- Listed configurations
- 33
CONFIGURATIONS
Choose from 33 available configurations.
Choose one power-supply SKU by 12V or 24V output, rated power, enclosure dimensions and case format. Selected 24V export versions are encapsulated. The 3 m power cable is a separate option, not a power-supply rating.
Use the search to narrow by voltage, color, length, plug, controller or model text.
SELECTION GUIDANCE
Confirm the complete requirement.
- Product selection
- Confirm the input voltage for the exact unit before ordering. Then match output voltage to the load and select adequate rated power from the same SKU. Use the terminal or lead arrangement specified for that model.
- Quantity
- Enter the project quantity, length or sample need.
- Destination
- Add destination and postal code in the request form.
- Documents
- Request only the files applicable to the selected model and market.
APPLICATIONS & NEXT STEPS
Product uses
rigid LED bars
cabinet lighting
low-voltage LED strip installations.
